Product Details:
Payment & Shipping Terms:
|
Use For: | Cargo | Driving Type: | Motorized |
---|---|---|---|
Displacement: | 151 - 200cc | Body Type: | Open |
Size: | 3500*1250*1360 | Tyre: | 4.50-12 Three Wheels Can Change With Each Other |
High Light: | Heavy Load 150CC Cargo Tricycle,Open Body 150CC Cargo Tricycle,Air Cooling 150CC Cargo Tricycle |
Features
. Features
1. Zongshen air cooled engine, high performance
2. Chasis and cargo box, all use pickling and electro painting
3. OEM is acceptable
4. Original factory located at Chongqing, mature supplying manufacturing system
Main features:
1. Choosing 150cc air cooling engine to ensure its competitive features
2. Good appearance, good quality with reasonable price.
3. Changable accessories options to meet your real demand.
4. If choose to use boostering rear axle, it can climb montainouse road for you easily
Advantages:
Technical specification:
Technical Paramter: | |
Model: | HH150ZH-B |
Engine Type: | 4 Stroke, single cylinder, air-cooled |
Displacement(ml): | 144.6 |
Compression ratio: | 9.0:1 |
Max. power & rotating speed: | 9.0kw/7500 r/min±300 r/min |
Rated .power & rotating speed: | 8.5kw/7500r/min±300r/min |
Max. torque & rotating speed: | 11N.m/6500r/min±225r/min |
Ignition: | CDI |
Fuel: | RQ-90 |
Dimension (L*W*H): | 3200*1250*1360 |
Net weight (kg): | 320 |
Rated Max. load (kg): | 850 |
Brake (F/R): | Drum/Drum |
Starting system: | Electrical/Manual pull |
Tire size (F/R): | 4.50-12 |
Transmission: | Shaft |
Ground clearance (mm): | 180 |
Rated Max.speed (km/h): | 60 |
Fuel Consumption (L/100km): | 3.5 |
Optional Parts:
Engine Optional | Model: air cooled; water cooled; both air and water cooled |
Displacement Choice:150cc;200cc;250cc | |
Low speed,high power, large torque | |
Cargo box Optional | Cargo box length can be chosen from 1.5m to 2.2m |
Model: Normal pattern; Strengthed pattern; Flower pattern | |
Tire Optional | 4.50-12; 5.00-12 ;5.50-13 |
Rear axle Optional | Normal rear axle---used for flat road condition and normally used to load light goods; |
Car normal rear axle---used for downslope condition, for loading heavier goods; | |
Boosting rear axle---used for grade climbing; loading heaviest goods on rough and moutainous road | |
Optional parts | 1.front hood cover; 2.fan; 3.MP3; 4.spare tyre; 5.jack; 6.tail light cover; 7.rear canavas 8. Driver Cabin |
SKD,CKD AS PER CUSTOMER REQUIREMENTS
1. Payment term?
A: T/T Other ways are also can be considered.
2. Delivery time?
A: 15-20 days. urgent order is acceptable.
3. MOQ?
A: 20 Set. But we suggest that you can buy a container of it, which is more cost-effective.
4. Package infomation?
A: CKD/SKD ;20GP container : 20sets ;40GP container: 48 sets.
5. What's your warranty term?
A: We offer different warranty time for different products. Pls contact us to get detail information.
6: Will you deliver right goods as we ordered? How can I trust you?
A: Yes, we will. We belive that honesty and credit is the key to build a nice and long-term business relationship. Our company is Alibaba's Gold suppliera and we have Trade Assurance $56,000.
7.Price?
A:We are manufacture and trading company with competitive price, distinct appearence.
8.Service center in Africa?
A:We have service center in Africa to help you develop business and make money.Since we have storehouse in there, it is more convenient for u to see sample tricycle.What's more, we can solve assemble and quality problem in time.
