Place of Origin:
Chongqing, China (Mainland)
Brand Name:
HUANGHE
Certification:
CCC.ISO9001
Model Number:
HH200ZH-S2
Quick Details
Recommend Advantages:
| Technical Details: | |
| Model: | HH200ZH-S2 |
| Engine Type: | 4 Stroke, single-cylinder, water-cooled |
| Displacement(ml): | 197 |
| Compression ratio: | 9.2:1 |
| Max. power & rotating speed: | 10.6kw/7500 r/min±300 r/min |
| Rated .power & rotating speed: | 10.0kw/7500r/min±300r/min |
| Max. torque & rotating speed: | 13.5N.m/6500r/min±225r/min |
| Idle speed: | 1400rpm |
| Ignition: | CDI |
| Fuel: | RQ-90 |
| Dimension (L*W*H): | 3400*1300*1360 |
| Net weight (kg): | 350 |
| Rated Max. load (kg): | 1000 |
| Brake (F/R): | Drum/Drum |
| Starting system: | Electrical/Manual pull |
| Tire size (F/R): | 5.00-12 |
| Transmission: | Shaft |
| Ground clearance (mm): | 180 |
| Rated Max.speed (km/h): | 65 |
| Fuel Consumption (L/100km): | 3.8 |
Package:
SKD,CKD AS PER CUSTOMER REQUIREMENTS
1. Payment term?
A: T/T or L/C. Other ways are also can be considered.
2. Delivery time?
A: 15-20 days.
Since we produce the big chassis and cargo box by ourselves, our factory can ensure the quickest delivery time. Normally we can delivery within 20 days after receiving the deposit.
3. MOQ?
A: One 20ft container of loading about 15-20 units.
4. What's your warranty term?
A: We normally offer 1% free spare parts for after-sale service.
5.Are there any Service center?
A:We have service centers in Africa. Since we have warehouses there, it is more convenient for u to see the sample tricycle. What's more, we can handle assembly and provide training for your workers on time.
