Product Details:
Payment & Shipping Terms:
|
Displacement: | 151 - 200cc | Driving Type: | Motorized |
---|---|---|---|
Use For: | Cargo | Body Type: | Open |
Battery: | 12v 120ah | Loading Capacity: | More Than 2000kg |
Voltage: | 12v | Maximum Speed: | 60km |
High Light: | 200cc Cargo Tricycle,12v 120ah Cargo Tricycle,Open Body Cargo Tricycle |
Quick Details
Technical Details: | |
Model: | HH200ZH |
Engine Type: | 4 Stroke, single cylinder, water-cooled |
Displacement(ml): | 197 |
Compression ratio: | 9.2:1 |
Max. power & rotating speed: | 10.6kw/7500 r/min±300 r/min |
Rated .power & rotating speed: | 10.0kw/7500r/min±300r/min |
Max. torque & rotating speed: | 13.5N.m/6500r/min±225r/min |
Idle speed: | 1400rpm |
Ignition: | CDI |
Fuel: | RQ-90 |
Dimension (L*W*H): | 3400*1300*1360 |
Net weight (kg): | 350 |
Rated Max. load (kg): | 1000 |
Brake (F/R): | Drum/Drum |
Starting system: | Electrical/Manual pull |
Tire size (F/R): | 5.00-12 |
Transmission: | Shaft |
Ground clearance (mm): | 180 |
Rated Max.speed (km/h): | 65 |
Fuel Consumption (L/100km): | 3.8 |
Configuration can be designed as client's requirements | |||
1.Color options: | |||
Red,Blue,White,Black etc. | |||
2.Engine options: | |||
Air cooled Engine :150cc,175cc,200cc,250cc | |||
Water cooled Engine :150cc,175cc,200cc,250cc | |||
3.Cargo box options: | |||
1.1m*1.6m/1.2m*1.7m/1.2m*1.8m/1.2m*2.0m/1.25m*2.0m/1.25*2.2m | |||
4.Rear axle options: | |||
Normal rear axle, Auto rear axle ,Liquid-brake rear axle, Boosting rear axle etc. | |||
5.Front shock absorber optional: | |||
43mm/50mm front shock absorber, front shock absorber with damper, double front shock absorber,etc. | |||
6.The tyres optional: | |||
4.5-12, 5.0-12. etc. | |||
7.Addtional Parts for choice : | |||
Sparetyre, Jack, Fan, Rear absorber, MP3, Radio, Glasses fender, Tent, seat. etc |
FAQ
Q1: Are you a factory or trading company?
Yes, acturally,we have one trading company and one big factory,our trade company charge for:
(1)The abroad marketing and sales;
(2)The "R &D" for new product;
(3)the export work in our country;
our factory charge for the pruchasement and produce,quality control,delivery and so on;
Q2: Could you accept OEM for us ?
Yes, we could accept and the minimum order is 60pieces.
Q3: Could I put our brand name on the product?
Yes ,we could accept and make it for you,we need your help to give us the authority letter before produce;
Q4: Could we have your catalog?
Yes, please contact us and we will send it right away.
Q5:Could we visit your factory and be your agent in our country?
Yes,you're welcomed to visit our factory,we could give you invitation letter if you need,and we will arrange to pick up you in our airport or railway station;
For our agent,you should have the market plan,and we must confirm the quantity one year,at the same time,you should show us your ability and deal with the after-sale service in your market;
Q6: What is your payment terms for our order?
By T/T , 30% prepaid, the balance should be paid before delivery.
